Half cells panels 144 cells solar panel solar cells solar modules 158.75*79.75mm mono poly solar cells 400w watts luxen for roof

FOB Reference Price:Get Latest Price
$0.19 - $0.24 / Watt | 100000 Watt/Watts (Min. Order)
Material:
Monocrystalline Silicon
Max. Power:
400
Number of Cells:
144
Lead Time:
Quantity(Watts) 1 - 1000 >1000
Est. Time(days) 7 Negotiable
Customization:
Customized logo (Min. Order: 100000 Watts)
Customized packaging (Min. Order: 100000 Watts)

More

Graphic customization (Min. Order: 100000 Watts) Less
Samples:
$0.23 /Watt | 1 Watt (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
LUXEN
Model Number:
LNSU-400M
Size:
2015*996*40mm
Certificate:
TUV CE ISO INMETRO IEC BIS
Type:
Standard Solar Panel
Product name:
LNSU-400M
Solar cell:
158.75*79.375mm
Application:
Solar Power System
Junction Box:
IP67/IP68 Rated
Warranty:
25 Years Output Power Guarantee
Frame:
Anodized Aluminium Alloy
Glass:
Glass 3.2mm tempered
Supply Ability
Supply Ability:
20000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
exquisite packaging
Port
shanghai
Picture Example:
package-img
package-img
Lead Time :
Quantity(Watts) 1 - 1000 >1000
Est. Time(days) 7 To be negotiated
Video Description
HOT PRODUCTS

Product Description


MONO
STCLNSU-390MLNSU-395MLNSU-400MLNSU-405MLNSU-410M
Maximum Power(Pmax)390W395W400W405W410W
Open Circuit Voltage(Voc)49.61V49.95V50.29V50.63V50.97V
Short Circuit Current(Isc)10.14A10.19A10.24A10.29A10.34A

Voltage at Maximum Power

                              (Vmpp)

40.63V40.93V41.24V41.54V41.84V

Current at Maximum Power

                               (Impp)

9.60A9.65A9.70A9.75A9.80A
Module Efficiency(%)19.43%19.68%19.93%20.18%20.43%



POLY
STCLNSU-365PLNSU-370PLNSU-375PLNSU-380PLNSU-385P
Maximum Power(Pmax)365W370W375W380W385W
Open Circuit Voltage(Voc)48.35V48.59V48.83V49.06V49.29V
Short Circuit Current(Isc)9.82A9.90A9.97A10.05A10.12A

Voltage at Maximum Power

                              (Vmpp)

38.87V39.03V39.18V39.34V39.49V

Current at Maximum Power

                               (Impp)

9.39A9.48A9.57A9.66A9.75A
ModuleEfficiency(%)18.19%18.44%18.69%18.93%19.18%



Mechanical Characteristics

Solar CellMono/Poly
No.of Cells144(6x24)
Dimensions2015x996x40mm
Weight24.5kgs
FrontGlass 3.2mm tempered glass
FrameAnodized aluminium alloy
Junction BoxIP67/IP68 rated(3 by pass diodes)
Output Cables4.0mm²
symmetrical length
300mm
ConnectorsMC4 compatible
Mechanical load test5400Pa
Operating Module Temperature-40°C to +85°C
Maximum System Voltage1500V DC(IEC) 1000V DC(UL)
Maximum Series Fuse Rating30A
Power Tolerance0/+5W
Temperature Characteristics

Nominal Operating Cell Temperature

 (Noct)

45±2°C
Temperature Coefficient of Pmax-0.36%/°C
Temperature Coefficient of Voc-0.29%/°C
Temperature Coefficient of Isc+0.05%/°C






Packaging & Shipping


Company Information




FAQ


1. Are you trading company or factory?
We are factory loacted at Suzhou,China. 20 minutes to Shanghai by High-speed rail.



2.How about the quality and price?
We use brand JASOLAR cell to guaranteed quality stability.And we can negotiate the price depends on the quantity.



3. When can you send the PV module if I order now?
If less than 3*20'GP containers, can be sent in one week.
If more than 3*20GP containers, can be sent in one month.
The shortest delivery time record is in five days with 5*40'HP containers.



4.How to pay?
We accept WesternUnion,TT,HSBC. And we accept L/C.
If you need other ways, please contact us for sure.
